STM32F3Discovery with Chebuzz F3 shield.

There is also limited support for the following boards which may be removed due to lack of users or commercial availability.

Port103R - Recommended for F1 developers.

STM32F3Discovery - Recommended for developers.

The F3 processor is faster, has built in USB support and supports more hardware without the need for additional adaptors and cables.Ĭleanflight also runs on the following developer boards: If you want a fully featured version of Cleanflight then the recommendation for new purchases is an STM32 F3 based board with 256KB of flash memory. The core logic is separated from the hardware drivers, porting to other processors is possible.

Stm32 driver f3 racing series#

Std mounting, 36mm x 36mm with 30.The current focus is geared towards flight controller hardware that use the STM32F303 and legacy STM32F103 series processors.

Stackable design, perfect for integrating with OSD's and power distribution boards.

JST-SH sockets only for 12C, UART2 and SWD.

Symmetrical design for tidy wiring installation.

Developer friendly debugging port (SWD) and boot mode selection.

Buzzer port for audible warnings and notifications.

Battery monitoring for voltage and current.

Dedicated 12C port for connection of OLED display.

Dedicated output for programmable LED's.

Stm32 driver f3 racing serial#

3 serial ports, these are not shared with the USB socket.

Supports direct connection of 3.3V Spektrum satellite receivers.

Supports direct connection of SBus, SumH, SumD, Spektrum 1024/2048, XBus receivers.

8 PWM output lines for ESC's and servo's.

Uses pin headers for major connections for excellent crash durability (supplied).Features the latest Accelerometer, Gyro and Mag/Compass and Baro/Altitude sensor technology.Race transponder built in, just turn up and race and have your lap times recorded.Micro SD card socket for black box recorder.Next generation STM32 F3 processor and fast ARM-Cortex M4 core.

Stm32 driver f3 racing manual#

The list of features and specs goes on and on, please look under the "Files" tab for the Manual and the Features list.

Stm32 driver f3 racing software#

The gyroscope and accelerometer sensors are connected to the fast SPI bus, this enables the software to get more data even quicker to help stabilize your craft even better. uses the ARM Cortex-M4 72Mhz CPU with Math co-processor (FPU) for efficient flight calculations that gets more done in less time. The Cleanflight software enables the precision flying you require for fast FPV racing. In conclusion, the F3 EVO uses advanced processor, sensor and software technologies to make your multirotor (drone) fly like it's on rails. The F3 EVO uses a similar layout to the F3 Acro and Deluxe boards, the stack pins, ESC/Servo outputs and connectors are in the same location for maximum mounting compatibility with existing products. The hardware was designed by the lead developer of Cleanflight to be more capable than the previous generation of STM32F1 based boards. Being open-source means that you too can contribute to the system. The F3 Racing Evo runs the open-source Cleanflight flight control (FC) software which has an ever growing community of friendly developers and users. The F3 EVO gives you all the features you need for the heart of your multirotor whether you are an FPV racer, aerobatic flyer or do aerial photography, it's the perfect choice. Analyze your race and flight telemetry/blackbox logs using the built-in micro SD card socket.

Stm32 driver f3 racing pro#

Featuring a race timing transponder system the F3 EVO Pro has been designed with the serious racer in mind. It has the latest sensors, race timing and logging technology backed by excellent connectivity options, all this at a very affordable price. It has been designed to give awesome flight performance in a stackable race ready package. The F3 Racing EVO flight controller has features that makes it the board of choice for your next multirotor (drone) racer build.
